| Useful Capacity (l) | 1400 |
| Internal Dimensions | 1150 x 1150 x 1030 mm |
| External Dimensions | 2200 x 1580 x 2670 mm |
| Vibration Table Size (Inches) | 36 x 36 |
| Acceleration Max. (gRMS) | 80.0 |
| Frequency Range Min. (Hz) | 4.0 |
| Frequency Range Max. (Hz) | 10000.0 |
| Pneumatic Vibrators | 9.0 |
| Temperature Change Rate On Air Over Range -60°C/+150°C and Viceversa | up to 100°C/min |
| Heating (kW) By Nichrome Heaters | 120.0 |
| Cooling | Liquid Nitrogen Expansion |
| Liquid Nitrogen Pressure Min. (bar) | 6.0 |
| Liquid Nitrogen Pressure Max. (bar) | 8.0 |
| Humidity (Optional) | Yes |
| Humidity Min. (%) | 20.0 |
| Humidity Max. (%) | 90.0 |
| Humidity Temp Min. (°C) | 30.0 |
| Humidity Temp Max. (°C) | 85.0 |
| Noise Level Min. dB(A) (At One Meter With Door Closed) | 78.0 |
| Noise Level Max. dB(A) (At One Meter With Door Closed) | 80.0 |
| Air Pressure for Vibration To Reach 80 gRMS (bar) | 9.0 |
| Air Pressure for Vibration To Reach 60 gRMS (bar) | 6.0 |
| Air Flow for Vibration (Nm3/h) | 210.0 |
| Amperage Max. (A) | 205.0 |
| Supply Voltage (Vac) | 400V ±10% 50Hz 3 + N + G |
|
