| Capacity | 337 litres |
| Internal Dimensions | 601 x 810 x 694 |
| External Dimensions | 875 x 1786 x 1765 |
| Weight | 720 |
| Temperature Range | -75°C to +180°C |
| Temperature Rate of Change | 4.5°C/min from -70°C to +180°C
2.3°C/min from +180°C to -70°C
|
| Humidity Range | 10% to 98% within the temperature range +10°C to +95°C |
| Dew Point Range With Plugs | N/A |
| Altitude Range | N/A |
| Power Supply Requirement | 400V / 3 Phase / 16 Amps + N + E |
| Compressed Air Requirements | N/A |
| Water Requirements | Demineralised Water |
| Drainage Requirements | Yes |
| Door Hanging (L/R) | Left |
| Window | Y |
| Window Width (mm) | 450 |
| Window Height (mm) | 550 |
| Cable Entry Ports | 1 x 80mm Left Hand Side
1 x 150mm Right Hand Side
|
| Type of Controller | Programmable Logic Controller |
| Castors | Yes |
| Number of Shelves | 1 |
| Type of Cooling System | Mechanical Air Cooled Cascade |
| Refrigerant Used | R23 R452A |
